| Keyboard |
・ Responsive Hammer Lite action
- 88 keys
- Grade-weighted hammers
- Matte key surfaces |
| Pedal |
・ F-1SP switch pedal
- Damper (on/off)
* Compatible with F-10H damper pedal |
| Sound |
| Piano Sound |
・ Harmonic Imaging (HI)
- Stereo sampling
- SK-EX recording
- 192 note maximum polyphony |
| Piano Resonance |
- |
| Piano Adjustment |
・Virtual Technician (1 parameters)
- Touch Curve |
| No. of Sounds |
17 voices |
| Reverb |
3 types |
| Brilliance |
- |
| Other Effects |
Preset |
| Output System |
| Speakers |
12 cm x 2 (full range speakers) |
| Output Power |
20 W (10 W x 2) |
| Headphone Enhancements |
- |
| Design |
| Display |
- |
| Key Cover |
- |
| Music Rest |
Detachable type (included) |
Product Size & Weight |
Width |
129.5 cm (51") |
| Depth |
26 cm (10 1/4") [music rest detached]
32.5 cm (12 3/4") [music rest attached] |
| Height |
15 cm (6") [music rest detached]
33 cm (13") [music rest attached] |
| Net Weight |
11 kg (24 1/4 lbs.) [music rest detached]
11.5 kg (25 1/2 lbs.) [music rest attached] |
Packing Size & Weight |
Dimensions |
140 (W) x 35 (D) x 26 (H) cm |
| Gross Weight |
18 kg |
| Available Finishes |
Black (ES60B) |
| Functions |
| Basic Functions |
Dual
Split
Transpose
Tuning
Speaker EQ
Speakers On/Off |
| Internal Songs |
Sound Demo |
15 sound demo songs |
| Piano Music |
- |
| Concert Magic |
- |
| Lesson Songs |
9 books, 377 pieces (via PiaBookPlayer app) |
| Internal Recorder |
Total Memory |
- |
| No. of Songs |
- |
| Parts |
- |
| Metronome |
Time Signatures |
1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8 |
| Drum Rhythms |
30 patterns |
| External Connectivity |
| Bluetooth * |
- |
| USB Audio Recorder |
Record/Playback |
- |
| Other Functions |
- |
| App Functions |
PianoRemote (iOS/Android)
PiaBookPlayer (iOS/Android) |
| Connector Jacks |
Headphone |
1 x 1/4" stereo jack (front) |
| MIDI |
USB-MIDI |
| Line Out |
1/4" L/MONO, R [unbalanced] |
| Line In |
- |
| USB to Host |
✔ |
| USB to Device |
- |
| Others |
Damper (for F-1SP, F-10H) |
| Power Supply |
| Power Consumption † |
7 W |
| Included Accessories |
| Power |
Power cable
AC adaptor (PS-129) |
| Bench |
- |
| Headphones |
- |
| Sheet Music |
- |
| Others |
Warranty Card *
Owner's Manual
Music Rest
F-1SP switch pedal |
