Elegance meets durability

Specially designed to meet the needs of those who require elegance, high quality and exceptional durability in an instrument, without a premium price tag, the 508 decorator console upright piano is a finely-crafted, superb sounding instrument that will provide satisfying musical enjoyment for years to come.

Gallery

close

  • 508 508 Satin Mahogany

close

  • 508 508 Satin Mahogany

OVERVIEW



OVERVIEW

Supremely stylish, yet extremely affordable

The 508 decorator console embodies three fundamental elements of a fine piano – a superior soundboard made of solid spruce, a durable back assembly with sturdy backposts, and our exclusive Ultra-Responsive Direct Blow Action. These important elements ensure a level of tone, touch and durability that will satisfy the needs of any pianist. Add a stylish cabinet with attractive, elegant lines and the result is a finely-crafted, superb-sounding instrument that will provide satisfying musical enjoyment for years to come.

TOUCH



TOUCH

508 508

The World’s Most Precise Piano Action

The 508 features our exclusive Ultra-Responsive™ Direct Blow action that offers extraordinary touch. Hammer heads are made with 100 percent wool felt. Hammer shanks and mouldings are made with top-quality maple.



To make the action resistant to climatic and seasonal changes in temperature and humidity, we pioneered the use of aluminium action rails, aluminium hammer rest rails and precision parts made of stable, low-friction ABS Styran.



508

Exclusive ABS Styran Action Parts

The innovative use of ABS Styran in our piano actions is one of the chief reasons why a Kawai piano will maintain stable touch and tone over time better than other pianos.



Endorsed by leading piano technicians and proven superior in scientific tests, ABS Styran is supported by over forty years of proven reliability in Kawai pianos.

TONE



TONE

508 508

Soundboards and Ribs

The most important sound-producing parts of a piano are the soundboard and ribs. The choice of materials and the manner in which they are assembled can greatly affect volume and tone quality.



Our wood technologists select only the finest spruce to ensure exceptional dynamic range and superb tone across the entire spectrum of sound. The 508 boasts an exceptionally large soundboard area (2,015 sq. in.) for greater tonal power and resonance.


508
Pinblocks

The pinblock must be constructed and finished to the highest quality standards to ensure optimum tuning stability over many years of use. The 508 pinblock is made from the finest hard rock maple, cross-laminated in 13 plies to assure that the tuning pins remain tightly fitted through a lifetime of music-making.

508
Bridges

The 508 bridge is made from select hard maple, individually notched for a clear, powerful tone quality.



Height is carefully set and matched to the iron plate for correct string pressure and optimal tonal transfer.



508

Tuning Pins

The 508 tuning pins are 64mm in length and manufactured to rigid specifications with nickel-plated carbon steel.



Our precision thread-cutting process produces a pin with tremendous “reverse-grip” holding power.



508

Back Posts

Back posts support the plate and help maintain its structural integrity over the lifetime of the piano.



Our laminated back post construction is designed for maximum rigidity to provide enhanced tuning stability and decades of reliable performance.

PERFORMANCE



PERFORMANCE

508 508

“Matched Strength” Plate Design

The cast iron plate is subjected to as much as 20 tons of string tension. We use modern CAD technology to match the strength and natural resonances of the plate to the requirements of its design. The proper combination of plate design, back post structure and string tension provides enhanced tuning stability for decades of reliable performance.



508

Longer Key Sticks

The 508 cabinet is built with added depth (24") to accommodate a longer key length for better control.



The extended 16 1/4" keys offer greater leverage at every point of the playing surface for a more even, controlled touch.



508

Cast Brass Pedals

Our exclusive Cast Brass Pedals are extremely rugged. Made with a permanently bonded brass layer over an aluminium core, they are significantly stronger and more durable than conventional “capped” pedals for lasting beauty and silent operation.



The centre pedal activates the mute rail for quiet practice.



508

Cabinet Design and Finishes

The "toe-block" design secures the piano's legs and strengthens overall cabinet integrity to handle the demands of rigorous institutional use.



Available in an attractive Mahogany Satin finish, the 508 is meticulously stained and coated to assure a beautiful and trouble-free finish.

SPECIFICATIONS



SPECIFICATIONS

Size Height 113 cm (44 1/2" cm)
Width 150 cm (59")
Depth 61 cm (24")
Weight 192 kg (424 lbs.)
Touch White key surfaces Acrylic
Black key surfaces Phenol
Action Ultra-Responsive
Hammer felts Single
Sound Soundboard Solid Spruce, Tapered
Speaking length of no.1 string 112 cm (44 1/8”)
Cutoff bar -
Agraffes -
Duplex scaling -
Back posts 5
Exterior design Pedals Soft, Muffler, Damper
Casters Single
Softfall -
Lock
Other features Steel reinforced keyslip & keybed

* Depending on market location. Specifications are subject to change without notice.
